brand BPW axles trailer axle for sale
1. Axle beam use 20Mn2 seamless pipe, through one-piece press
forging and special heat-treatment, which has great over loading capacity and high intensity.
2. Axle spindle,which was processed by digital controlled lathe, is made of alloy material.
The bearing position is processed by the method of hardending
operation,therefore the bearing can be fixed by hand instead of
heating, also convenient for maintain and fixing.
3. Axle spindle is connected by the by submerged arc welding, which make the whole beam more reliable and solid.
4. Axle bearing position is used the grinding machine to keep the
bearing at the same level, after processing, it can assure that the
concentricity within 0.02mm strictly.
5. Axle grease lubricant is supplied by EXXON Mobile which could providehigh lubricating performance and protect bearing
well.
6. Axle brake lining is high performance, non-asbestos, non-pollution and long service life.
To make check and replace easily, also come with the position of
the exhaustion to remind customer to check and maintain.
7.Axle bearing is adopted famous brand in China, with the advantages of over loading capability, High rotating speed, good intensity, abrade resistant and heat
resistant.
Other Products
Dear customer, our company supplies many other trailer parts, such
as suspension, landing gear, fifth wheel, king pin and other parts
except axle.
Axle: American type axle, German type axle, 12T/13T/14T/16T/20T
Suspension: Leaf spring mechanical suspension, air suspension,
bogie suspension
Landing gear: Outboard, Inboard, one-side operation, both-sides
operation
Fifth wheel: 50#, 90#
King pin: 2 inch, 3.5inch, wielded, bolted
Leaf spring: 90 width, 75width, 100 width, 13leafs, 16leafs
Air chamber: T24, T24/24, T30, T30/30
Product Features
. One high-quality low-alloy axde tube has strong carrying capacity
and high bending strength. .
The axle tube tempered as a whole and then quenching optimized
which made by finishing high-precision machinery. .
Environmentally friendly Non-asbestos brake shoe which increase the
wear life of more than 25%
. Brake components have strong interchangeability, S-camshaft, so
that have more flexible and reliable brake action . Adopt Mobil
XHP222 grease which has maintenance-free longer. ·
Adopt heavy-duty bearings which specially used for heavy vehicles
have strong interchangeability. . The unique beauty with O-ring of
the steel wheel cover has special good performance. . ABS Optional.
